ASTM A312 TP347 Stainless Steel Seamless Pipe AISI 347H DIN1.4541 With Mill Test Certificates (MTC) According to EN 10204 3.1

Ampliación de imagen : ASTM A312 TP347 Stainless Steel Seamless Pipe AISI 347H DIN1.4541 With Mill Test Certificates (MTC) According to EN 10204 3.1

Datos del producto:

Lugar de origen:	China.
Nombre de la marca:	MITTEL
Certificación:	SGS ISO MTC
Número de modelo:	347H

Pago y Envío Términos:

Cantidad de orden mínima:	100 kgs
Precio:	3.55-5.45 USD/KG
Detalles de empaquetado:	Caja de madera
Tiempo de entrega:	7 días después de recibir el depósito
Condiciones de pago:	L/C, T/T
Capacidad de la fuente:	80000 kgs

Contacto

ASTM A312 TP347 Stainless Steel Seamless Pipe AISI 347H DIN1.4541 With Mill Test Certificates (MTC) According to EN 10204 3.1

descripción

Aplicación:	Construcción, decoración, industria, calderas, productos químicos	Estándar:	Estruendo, ASTM, JIS, AISI
Grado de acero:	347 347H DIN1.4541	Tipo:	Sin costura
Espesor:	0,5 ~ 60 mm	Longitud:	3000 mm ~ 6000 mm, solicitud del cliente
Forma:	Redondo, cuadrado, rectángulo.	Diámetro exterior:	6-762m m
Técnica:	Fría dibujada	Superficie:	Recocido, decapado

ASTM A312 TP347 Stainless Steel Seamless Pipe AISI 347H DIN1.4541 With Mill Test Certificates (MTC) According to EN 10204 3.1

Name	Seamless Steel Pipe
Standard	ASTM, GB, JIS, DIN, EN, AISI
Material Grade	TP304/TP304L /TP316/ TP316L /TP347/ TP347H /TP321/ TP321H /TP310/ TP310S/TP310H
	TP317L/TP317
	S31803/S32205 S32750 S32760 S32304 S32101
Outer Diameter	Seamless Pipe: 6mm-610mm
Thickness	Seamless Pipe: 0.6mm - 60mm
Length	5.0-5.8 MTR or as customers' request
Tolerance	According to the Standard.
Test	UT,ET,HT,RT,ect, and others according to the standard,or as the requests of the customers
Sample	Yes
Certificate	ISO 9001:2008
Marking	Standard, Grade, Size, Length and Heat No.
Packing Details	Plastic bags in bundles, wooden cases or depend on buyer’s requirement
Payment Terms	T/T, D/P at sight, L/C at sight
Delivery Time	Depend on the quantity
Supply Ability	1000 tons per month

General Properties

Alloy 347 (UNS S34700) is columbium stabilized austenitic stainless steel plate with good general corrosion resistance and somewhat better resistance in strong oxidizing conditions than 321 (UNS S32100). It has excellent resistance to intergranular corrosion after exposure to temperatures in the chromium carbide precipitation range of 800 – 1500°F (427 – 816°C). The alloy has good oxidation resistance and creep strength to 1500°F (816°C). It also possesses good low temperature toughness.

Alloy 347H (UNS S3409) stainless steel plate is the higher carbon (0.04 – 0.10) version of the alloy. It was developed for enhanced creep resistance and for higher strength at temperatures above 1000°F (537°C). In most instances, the carbon content of the plate enables dual certification.

Alloy 347 stainless steel plate cannot be hardened by heat treatment, only by cold working. It can be easily welded and processed by standard shop fabrication practices.

Corrosion Resistance

Alloy 347 stainless steel plate exhibits good general corrosion resistance that is comparable to 304. It was developed for use in the chromium carbide precipitation range of 800 – 1500°F (427 – 816°C) where un-stabilized alloys such as 304 are subject to intergranular attack. In this temperature range, the overall corrosion resistance of Alloy 347 stainless steel plate is superior to Alloy 321 stainless steel plate. Alloy 347 also performs somewhat better than Alloy 321 in strongly oxidizing environments up to 1500°F (816°C).

The alloy can be used in nitric solutions, most diluted organic acids at moderate temperatures and in pure phosphoric acid at lower temperatures and up to 10% diluted solutions at elevated temperatures. Alloy 347 stainless steel plate resists polythionic acid stress corrosion cracking in hydrocarbon service. It can also be utilized in chloride or fluoride free caustic solutions at moderate temperatures.

Alloy 347 stainless steel plate does not perform well in chloride solutions, even in small concentrations, or in sulfuric acid.

Chemical Analysis

Weight % (all values are maximum unless a range is otherwise indicated)

Element	347	347H
Chromium	17.00 min.-19.00 max.	17.00 min.-19.00 max.
Nickel	9.00 min.-13.00 max.	9.00 min.-13.00 max.
Carbon	0.08	0.04 min.-0.10 max.
Manganese	2.00	2.00
Phosphorus	0.045	0.045
Sulfur	0.03	0.03
Silicon	0.75	0.75
Columbium & Tantalum	10 x (C + N) min.-1.00 max.	8 x (C + N) min.-1.00 max.
Iron	Balance	Balance

Mechanical Properties

Typical Values at 68°F (20°C)

Yield Strength 0.2% Offset		Ultimate Tensile Strength		Elongation in 2 in.	Hardness
psi (min.)	(MPa)	psi (min.)	(MPa)	% (min.)	(max.)
30,000	205	75,000	515	40	201 Brinell

Fabrication Data

Alloy 347 stainless steel plate can be easily welded and processed by standard shop fabrication practices.

Cold Forming

The alloy is quite ductile and forms easily.

Hot Forming

The high sulfur content of Alloy 303 also has a detrimental impact on hot workability. If hot forming is required, once again, 304 should be considered as an alternate selection.

Machining

The cold work hardening rate of 347 stainless steel plate makes it less machinable than 410 stainless steel, but similar to 304. The table below provides relevant machining data.
