EN10204 DIN 1.7225 42CrMo4 +QT Case Hardning Cold Drawn Normalized Steel Bar 14*3000mm

Certificación
CHINA JIANGSU MITTEL STEEL INDUSTRIAL LIMITED certificaciones
CHINA JIANGSU MITTEL STEEL INDUSTRIAL LIMITED certificaciones
Comentarios de cliente
ésta es la segunda orden l compra esta compañía, calidad es muy buena, lo mismo a que la calidad .we del europure irá en ccooperate con esta compañía.

—— Andrew Greg - Turquía

la hoja de acero inoxidable de 200 toneladas se llega el 10 de octubre de 2014, la calidad es muy buena., entrega tiempo es muy rápida él es muy afortunada nosotros encuentra esta fábrica

—— Cardo de Mechile Kilar - Brazial

¡Tenemos cooperar con esta fábrica muchos años, todo vamos mismo Well.l como esta fábrica!

—— Tony Hilton - Polonia

Ésta es nuestra tercera compra de Mittel, calidad del tiempo es mismo mercancías, nosotros está alegre encontrar esta fábrica confiable

—— Natalya Ugay-Rusia

La calidad es muy buena y plazo de expedición muy rápido, queremos hacer negocio largo de los términos con esta compañía

—— Pongpol Pluemsati-Tailandia

Estoy en línea para chatear ahora

EN10204 DIN 1.7225 42CrMo4 +QT Case Hardning Cold Drawn Normalized Steel Bar 14*3000mm

EN10204  DIN 1.7225  42CrMo4 +QT Case Hardning Cold Drawn Normalized Steel Bar 14*3000mm
EN10204  DIN 1.7225  42CrMo4 +QT Case Hardning Cold Drawn Normalized Steel Bar 14*3000mm EN10204  DIN 1.7225  42CrMo4 +QT Case Hardning Cold Drawn Normalized Steel Bar 14*3000mm EN10204  DIN 1.7225  42CrMo4 +QT Case Hardning Cold Drawn Normalized Steel Bar 14*3000mm

Ampliación de imagen :  EN10204 DIN 1.7225 42CrMo4 +QT Case Hardning Cold Drawn Normalized Steel Bar 14*3000mm

Datos del producto:
Lugar de origen: Porcelana
Nombre de la marca: MITTEL TISCO BAO STEEL
Certificación: ISO, CE, BV SGS MTC
Número de modelo: 42CrMo4
Pago y Envío Términos:
Cantidad de orden mínima: 100KGS
Precio: 1.55-2.5 USD/KG
Detalles de empaquetado: caja de madera
Tiempo de entrega: 7 dias
Condiciones de pago: LC, T/T
Capacidad de la fuente: 850000KGS

EN10204 DIN 1.7225 42CrMo4 +QT Case Hardning Cold Drawn Normalized Steel Bar 14*3000mm

descripción
Grado de acero: Acero aleado Aleación o no: es aleación
Técnica: Fría dibujada Solicitud: Barra de acero estructural
Tipo: Barra de acero de aleación Estándar: ASTM, ESTRUENDO, AISI, JIS
Forma: Redondo, cuadrado Longitud: 1m-6m
Nombre del producto: Barras redondas de acero aleado 42crmo4 qt Tratamiento superficial: Negro/peladura/polaco/trabajado a máquina
Diámetro: 12 mm a 650 mm Condición de entrega: recocido
Dimensiones: Diámetro de 8 a 60 mm Calificación: 42CrMo4
Tratamiento térmico: +Annealed normalizado +Quenched + moderó

EN10204 DIN 1.7225 42CrMo4 +QT Case Hardning Cold Drawn Normalized Steel Bar 14*3000mm

chemical composition
component C Si Mn P S Cr Ni Cu Mo
minimum value 0.38 0.17 0.5 - - 0.9 - - 0.15
maximum value 0.45 0.37 0.8 0.035 0.035 1.2 0.3 0.3 0.25
Approximate comparison table
  ISC CNS JIS KS ASTM/AISI UNS ISO DIN EN/DIN W-Nr. NF EN/NF EN Digital brandGB SS14 BS EN/BS
42CrMo A30422 SCM440 SCM440
SCM440H
SCM440 4140 G41400 42CrMo4 42CrMo4 1.7225 42CD4 42CrMo4 1.7225 2244 708M40
Product Description
Commodity
Cold Drawing / Drawn Flat/ Square / Rectangular / Rectangle / Hexagonal / Special Shape Rods Bars
Grades
Carbon steel
SAE 1018 , A36, SS400, S235JR, Q235, SAE 1020, S20C , 1.0402, 20GB, CK22,
SAE 1045 ,S45C, C45, CK45, EN8 ,1.1191
Alloy steel
SAE 5120 , 20Cr, Scr 420H, 20Cr4, SAE 5140 , 40Cr,SCr440, 520M40,
SAE 4130 , 30CrMo, SCM430, SCM420, SAE 4140 , 42CrMo4, EN19, SCM440,
708A42, 708M40, SAE 4340, 40CrNiMoA,871M40 , SNCM439
Specification
Round Bar
5mm to 100mm
Square bar
5*5mm to 120*120mm
Flat bar
5*20mm to 20*100mm
hex bar
5mm to 120mm
hexagonal bar
5mm to 120mm (side to side)
Length
4-12m random length or as per request fixed length
Surface
Bright, or dark as per required
Packing
Wrapped by plastic clothes and steel strips
Delivery Condition
BK, BKW, GBK, NBK
Container
Size
20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)
Application
hardware tools, auto parts, standard parts, fasteners common shaft, machinery manufacturing, light industry, hardware, bicycles,
cars, motorcycles, textile machinery, transformers and other machinery industry.
Advantages
greater size accuracy, straightness and increased tensile and yield strength as well as improved machinability
MOQ
1 tons






mechanical behavior

Material Diameter of sample
d
mm
Heat treatment or condition. Tensile strength
σb
Mpa
Point of yield
σs
Mpa
Ratio of elongation
δ
%
Reduction of section
ψ
%
hardness
HBW
Shock absorption energy
KV2 J
ASTM 5115
45Cr
d=15 Quenching + tempering ≥735 ≥490 ≥11 ≥45 ≤179 ≥55
ASTM 5120
20Cr
d=15 Quenching + tempering ≥835 ≥540 ≥10 ≥40 ≤179 ≥47
ASTM 5130
30Cr
d=25 Quenching + tempering ≥885 ≥685 ≥11 ≥45 ≤187 ≥47
ASTM 5135
35Cr
d=25 Quenching + tempering ≥930 ≥735 ≥11 ≥45 ≤207 ≥47
ASTM 5140
40Cr
d=25 Quenching + tempering ≥980 ≥785 ≥9 ≥45 ≤207 ≥47
ASTM 5145
45Cr
d=25 Quenching + tempering ≥1030 ≥835 ≥9 ≥40 ≤217 ≥39
ASTM
4119
d=30 Quenching + tempering ≥410 ≥265 ≥24 ≥60 ≤179 ≥110
ASTM 4130 d=25 Quenching + tempering ≥930 ≥785 ≥12 ≥50 ≤229 ≥63
ASTM 4317 d=25 Quenching + tempering ≥980 ≥835 ≥12 ≥45 ≤229 ≥63
ASTM 4140 d=25 Quenching + tempering ≥1080 ≥930 ≥12 ≥45 ≤217 ≥63
GB38CrMoAI/
JIS SCM645
d=30 Quenching + tempering ≥980 ≥835 ≥14 ≥50 ≤229 ≥50
ASTM 6150 d=25 Quenching + tempering ≥1280 ≥1130 ≥10 ≥40 ≤255 d=25
ASTM 4142 d=25 Quenching + tempering ≥980 ≥785 ≥10 ≥45 ≤217 ≥63



EN10204  DIN 1.7225  42CrMo4 +QT Case Hardning Cold Drawn Normalized Steel Bar 14*3000mm 0

FAQ

1. Who are we?
Our headquarter is located in WUXI CITY , China. Since 2012, we have sold to North America (60.00%), Western Europe (14.00%) and South America (6.00%). There are about 11-50 people in our office.

2. How do we guarantee quality?
Always provide pre-production samples before mass production;
Always carry out final inspection before shipment;

3. What can you buy from us?
Copper, aluminum, die steel, titanium, customized machine parts
4. Why should you buy from us instead of other suppliers?
The company has 25 years of production experience. It has advanced precision production equipment, modern large warehouse, 200000 tons of inventory goods and a number of long-term stable cooperative customers.

5. What services can we provide?
Accepted delivery conditions: FOB, CFR, CIF, EXW
Accepted payment currency: US dollar, Euro, Japanese yen, Canadian dollar, Australian dollar, Hong Kong dollar, British pound, RMB, Swiss franc;
Accepted payment type: T/T, L/C, D/P D/A, PayPal;
Optional ports: Tianjin, Shanghai, Guangzhou;
Spoken: English, Chinese

6. How can we get your price?
A. We need the following information to quote for you:
1). Product Name
2). standard
3). Material grade (chemical composition)
4). dimension
5). amount
6). Special part drawin



EN10204  DIN 1.7225  42CrMo4 +QT Case Hardning Cold Drawn Normalized Steel Bar 14*3000mm 1EN10204  DIN 1.7225  42CrMo4 +QT Case Hardning Cold Drawn Normalized Steel Bar 14*3000mm 2
